GRUNDFOS VERTICAL MULTISTAGE

GRUNDFOS VERTICAL MULTISTAGE PUMP
MODEL- CR

Specification

• Discharge Size 1/4″ (32mm.) to 4″ (100mm.)
• Power Output : 0.37kW – 45kW.
• Capacity : 0.7 – 120 Q/Hr
• Head : 5M – 322M.

Material

• Casing : Stainless Steel (AISI304)
• Impeller : Stainless Steel (AISI304)
• Shaft : Stainless Steel (AISI431)
• Mechanical Seal (Sic/Sic/EPDM)
• Max.Pressue Working 20 – 33bar
• Max. Liquid Temp. -20 to +120C.

Technical Data

• Volt 220-240Vac. 1PH / 380-415 Volt 3PH
• Speed RPM. 2900 @ 50Hz.
• Insulation Class F
• Degree Protection IP55.

Grundfos Pump รุ่นอื่นๆ โปรดสอบถาม
